NLB allows all of the computers in the cluster to be addressed by the same set of IP addresses, and it maintains a set of unique, dedicated IP addresses for each host. For load-balanced applications, when a host fails or goes offline, the load is automatically redistributed among the computers that are still operating. Network Load Balancing (NLB) is a clustering functionality that is implemented by Microsoft on Windows 2000 Server and Windows Server 2003 operating systems. NLB uses a distributed methodology or pattern to equally split and balance the network traffic load across a. May 27, 2004  Switches maintain a database of MAC addresses, both manually configured (static) and dynamically learned entries. During troubleshooting, it may be helpful to investigate the entries in the MAC table. To view the whole MAC table, use the following command from enable mode: show mac-address-table To list only the dynamically learned entries in the MAC table. HP Procurve 2810 - Multicast/Microsoft NLB One of my customer is using HP Procurve 2810 and he wants to configure Microsoft NLB. For this he wants to configure static Multicast MAC address in the switch's CAM table so that it knows how to switch multicast traffic appropriately instead of flooding. But mac address table multicast in switch access is empty. Swtich#show mac address-table multicast vlan 227. Vlan Mac Address Type Ports- - - -May be this is the cause of the problem. I don't know why the switch is not filling in the mac table if it konws.

  1. Microsoft Nlb Show Mac Address-table Address Empty 2017
  2. Microsoft Nlb Show Mac Address-table Address Empty Free
  3. Microsoft Nlb Show Mac Address-table Address Empty To Print

We can find mac address (physical address) of a computer using the command ‘getmac‘. This can be used to get mac address for remote computers also. Below are few examples on how to use this command. It works on XP, Vista, Windows 7, Server 2003 and Server 2008 operating systems.

Get mac addresses from CMD

Just run the command getmac to get the mac addresses. Find an example below.

This command does not show mac addresses for the network connections which are disabled. You can run ncpa.cpl and check which NICs are disabled. Further, I have received comments that this command does not help identify the mac address for a specific device. For example, if I need to get the mac address for my WiFi card, output of getmac command is not helpful. We can use ipconfig command to deal with this.

Get mac address of a remote computer

We can retrieve the mac addressses for a remote computer using nbtstat command.
Example:

Alternatively, We can run the below command to retrieve the mac addresses of a remote computer.

remote_computer : Full name of the remote computer or IP address
username and password are of the account on the remote computer.

Example:

If you do not want to specify the password, you can skip /p parameter. You will be prompted to enter the password and the command execution will take place after that.

Errors:

Using getmac command we can retrieve the mac addresses of the machines running windows OS only. If you try this for a Linux machine you would get the error “The RPC server is unavailable.”

If you provide incorrect password, the command would fail with the error message “Logon failure: unknown user name or bad password.”

Also Read:
Windows CMD commands reference

Introduction

This document describes how to configure the Cisco Catalyst switches in order to interact with Microsoft Network Load Balancing (NLB).

Prerequisites

Requirements

There are no specific requirements for this document.

Components Used

The information in this document is based on these software and hardware versions:

  • Cisco Catalyst 6500 Series switches with Supervisor Engine 2T (Sup2T) that run Cisco IOS速 Software Version 15.1(1)SY1
  • Cisco Catalyst 4948 Series switches that run Cisco IOS Software Version 15.0(2)SG7
  • Microsoft Windows Servers

Note: Consult the appropriate configuration guide for the commands that are used in order to enable these features on other Cisco platforms.

The information in this document was created from the devices in a specific lab environment. All of the devices used in this document started with a cleared (default) configuration. If your network is live, make sure that you understand the potential impact of any command.

Upgrade to Office 365 and get the latest Office applications, installs on multiple PCs/Macs and devices, 1 TB OneDrive cloud storage per user, tech support, and other services with your subscription. Microsoft office mac stand alone. Office 365 customers get the new Office for Mac first. You’ll have Office applications on your Mac or PC, apps on tablets and smartphones for when you're on the go, and Office. Shop Office Standalone Applications. Jan 22, 2018  TeresaBass Created on January 22, 2018 Mail merge Office for Mac 2016 (stand alone) on Mac OS High Sierra Using Excel as the data source, when trying to mail merge in Word, getting the error message saying that the text converter is missing. Sep 25, 2018  Office 2019 is the stand-alone, perpetual license version of Office. It’s just like Office was in the days before the subscription-based Office 365 was in play. You make a one time purchase, and you get to keep on using it as long as you want—on one PC or Mac.

Background Information

The NLB technology can be used in order to distribute client requests across a set of servers. In order to ensure that clients always experience acceptable performance levels, Microsoft Windows NLB provides the ability to add additional servers so that you can scale out stateless applications, such as IIS-based web servers, as client load increases. In addition, it reduces downtime that is caused by servers that malfunction.

Microsoft Windows NLB is a clustering technology that is offered as a part of all Windows 2000 Server and Windows 2003 Server family operating systems. It provides a single virtual IP address for all clients as the destination IP address for the entire cluster.

You can configure NLB to work in one of these three modes:

  • Unicast mode
  • Multicast mode
  • Internet Group Management Protocol (IGMP) mode
Microsoft Nlb Show Mac Address-table Address Empty

Unicast Mode

Here are some notes about the use of NLB in Unicast mode:

  • In Unicast mode, NLB replaces the actual Media Access Control (MAC) address of each server in the cluster with a common NLB MAC address. When all of the servers in the cluster have the same MAC address, all of the packets that are forwarded to that address are sent to all of the members in the cluster. The NLB creates a fictitious MAC address and assigns it to each server in the NLB cluster. The NLB assigns each NLB server a different fictitious MAC address, based on the host ID of the member. This address appears in the Ethernet frame header.
  • The MAC address is used in the Address Resolution Protocol (ARP) header, not the Ethernet header. The switch uses the MAC address in the Ethernet header, not the ARP header. This causes an issue when a packet is sent to the NLB cluster with the destination MAC address as the cluster MAC address 00-bf-ac-10-00-01. The switch views the Content Addressable Memory (CAM) table for the MAC address 00-bf-ac-10-00-01, and since there is no port registered with the NLB cluster MAC address 00-bf-ac-10-00-01, the frame is delivered to all of the switch ports. This introduces unicast flooding. In order to avoid flooding, Cisco recommends that you use a dedicated VLAN for NLB so that the flooding is constrained.

Multicast Mode

Here are some notes about the use of NLB in Multicast mode:

  • In Multicast mode, the system administrator clicks the Multicast button in the Microsoft NLB configuration GUI. This choice instructs the cluster members to respond to the ARPs for their virtual address with the use of a multicast MAC address, such as 0300.5e01.0101.
  • The ARP process does not complete for multicast MAC addresses (this breaks RFC 1812). A static MAC address is required in order to reach the cluster outside of the local subnet.
  • The virtual IP address is 10.100.1.99 and the multicast MAC address is 0300.5e01.0101. Enter this command in order to populate the ARP table statically:

  • Since the inbound packets have a unicast destination IP address and a multicast destination MAC address, the Cisco device ignores this entry and the unicast floods each cluster-bound packet. In order to avoid this flooding, insert a static mac-address-table entry in order to switch the cluster-bound packets in the hardware:

Note: When you statically map a MAC address to multiple ports, it is only supported by the software on the Cisco Catalyst 4500 Series switch. Also, the use of this configuration on the Catalyst 4500 Series switch might cause high CPU. In order to avoid this problem, you can isolate the NLB to a specific VLAN, add only the static ARP entries, and allow flooding on that VLAN.

IGMP Mode

Here are some notes about the use of NLB in IGMP mode:

  • The use of NLB in IGMP mode requires the least amount of manual configuration. The virtual MAC address falls within the Internet Assigned Numbers Authority (IANA) range and starts with 0100.5exx.xxxx. Since the MAC address now conforms to IANA specifications, the Cisco switches can dynamically program the MAC address with the use of IGMP snooping. This removes the need to manually program the MAC address to the port maps that are required in Multicast mode in order to prevent flooding to the VLAN.
  • The IGMP snooping programs the virtual MAC address for you once the switch receives a membership report from a member in the cluster. An Mrouter port must also be programmed for the NLB VLAN with the use of either Protocol Independent Multicast (PIM) or the IGMP querier feature.
  • Since the virtual IP address uses a multicast MAC address, it is unreachable outside of the local subnet. In order to address this, you must configure a static ARP entry on each device with a Layer 3 (L3) interface in the cluster VLAN. Complete this in the same fashion as with Multicast mode. For example, if the virtual IP address is 10.100.1.99 and the multicast MAC address is 0100.5e01.0101, use this command in order to populate the ARP table statically:

Caveats

Here are important notes to keep in mind when you use NLB in IGMP mode:

This site uses cookies for analytics, personalized content and ads. By continuing to browse this site, you agree to this use. Microsoft intellimouse explorer 2.0 driver mac.

  • As tracked in Cisco bug ID CSCsw72680, you cannot use PIM on the NLB VLAN Switch Virtual Interface (SVI) with certain versions of code. View the bug details for the code releases that address this issue or use the IGMP snooping querier feature.
  • As tracked in Cisco bug IDCSCsy62709, packets are duplicated for all of the traffic that is routed to the NLB servers in IGMP mode. View the bug details for the affected code versions.
  • Due to a hardware limitation that is tracked by Cisco bug ID CSCug49149, the NLB traffic cannot be sent across a distributed Etherchannel on the same 6708 linecard when the switch runs in either PFC3B or PFC3C mode. The port-channel must be cabled so that all of the member links are on the same forwarding engine.

Configure

This section describes how to configure NLB for the Cisco Catalyst 6500 and 4948 Series platforms that run in Multicast or IGMP mode.

Network Diagram

Configuration for Multicast Mode

This section describes how to configure NLB for the Cisco Catalyst 6500 and 4948 Series platforms that run in Multicast mode:

Here are some important notes about this configuration:

  • The interface Vlan100 ip address value configures the user VLAN.
  • The interface Vlan200 ip address value configures the NLB cluster VLAN. It is important that you configure the default gateway of the Microsoft Server to this address.
  • The arp 10.100.1.88 0300.5e01.0101 ARPA includes all of the L3 interfaces in the VLAN and is the virtual IP address of the NLB cluster servers.
  • The mac address-table static 0300.5e01.0101 vlan 200 interface creates a static MAC entry to port mapping in the switch for the multicast virtual MAC address.

Note: Ensure that you use Multicast mode on the NLB cluster. Cisco recommends that you do not use multicast MAC addresses that begin with 01 because they are known to have a conflict with the IGMP setup.

Note: The mac address-table static 0300.5e01.0101 vlan 200 interface creates a static entry in the switch for the multicast virtual MAC address. It is important to remember that all of the trunk interfaces that carry NLB traffic between the switches must be added. Once a static MAC address is defined, flooding is constrained. If you forget to include an interface, the NLB cluster breaks.

Configuration for IGMP Mode

This section describes how to configure NLB for the Cisco Catalyst 6500 and 4948 Series platforms that run in IGMP mode:

Here are some important notes about this configuration:

  • The ip igmp snooping querier enables the snooping querier feature.
  • The ip igmp snooping querier address 10.200.1.1 configures the snooping querier for the NLB VLAN.
  • The user VLAN is interface Vlan100.
  • The NLB cluster VLAN is interface Vlan200. It is important that you configure the default gateway of the Microsoft Server to this address (ip address 10.200.1.1 255.255.255.0).
  • The arp 10.100.1.99 0100.5e01.0101 ARPA is the virtual IP address of the NLB cluster servers. The static ARP must be on all of the L3 interfaces in the VLAN.

Microsoft Nlb Show Mac Address-table Address Empty 2017

Note: There is no need to configure static entries, as IGMP snooping does this dynamically in this mode. Also, no special configuration for this mode is required on the downstream Layer 2 (L2) switches.

Microsoft Nlb Show Mac Address-table Address Empty Free

Verify

Use this section to confirm that your configuration works properly.

Microsoft Nlb Show Mac Address-table Address Empty To Print

Note: The Output Interpreter Tool (registered customers only) (OIT) supports certain show commands. Use the OIT to view an analysis of show command output.

Multicast Mode Verification

Enter the show ip arp command in order to view the ARP cache:

Enter the show mac address-table static command in order to view a specific MAC address table static and dynamic entry or the MAC address table static and dynamic entries on a specific interface or VLAN:

IGMP Mode Verification

Enter the show ip arp command in order to view the ARP cache:

Enter the show ip igmp snooping mrouter in order to view the Mrouter port that is programmed by the queries received from the upstream snooping querier:

Enter the show mac address-table multicast igmp-snooping in order to view the dynamically-added MAC address that is learned from IGMP snooping and the member ports:

Enter the show ip igmp snooping groups in order to view the port list of cluster members that joined the multicast group:

Troubleshoot

There is currently no specific troubleshooting information available for this configuration.
